XL4015E 5A 75W DC-DC Adjustable Step-Down Module Regulated Power Supply Module With Voltage Display
XL4015E 5A 75W DC-DC Adjustable Step-Down Module Regulated Power Supply Module With Voltage Display
Exclusive Deals End Soon!
Save 5% on 2+ Items • Save 10% 3+ Items • Save 15% on 10+ Items
Applies automatically in cart & checkout • No code needed
Estimated delivery: 10 Dec - 15 Dec (exact time at checkout)
Couldn't load pickup availability
Shipping Information
Shipping Information
FREE SHIPPING to UK & 40+ countries. Fully insured.
Delivery: Estimated times shown at checkout based on your location (typically 6-13 days total including 1-3 days handling)
No hidden fees on orders under £135 (orders over £135 may have import duties)
Ships from China via tracked DDP service. Order by 12 AM London time for next-day dispatch.
30-Day Money-Back Guarantee
30-Day Money-Back Guarantee
Return unused items within 30 days (you pay return shipping). Faulty items covered at no cost to you.
Right Part Guarantee
Right Part Guarantee
Get exactly what you ordered or your money back, including shipping. 30 days, no questions asked.
Hassle-Free Returns
Hassle-Free Returns
Start your return online in seconds. No forms, no hassle.
Trusted by 80,000+ DIY & repair professionals
Module performance and features:
1. With voltmeter display and voltmeter can be self-calibrating, using a more advanced voltage microprocessor, voltmeter error 0.05V, range 0-40V (Note: To ensure the accuracy of the voltmeter, please ensure that the input voltage is above 4.5V)
2. With power indicator, touching the button to switch the measurement of input or output voltage, and there is an indicator to show which voltage is being measured, and save the settings, even if the power is off and on again
3. Voltmeter can be turned off, when not needed when touching the left button can be easily realized
4. With terminal block, easy to use without soldering iron, and retain the soldering wire junction point
5. Input voltage 4.0-38V (input voltage must be higher than output voltage by more than 1.5V)
6. Adjustable output voltage range 1.25V-36V continuously adjustable (input voltage must be 1.5V higher than output voltage)
7. Output current up to 5A, it is recommended to use within 4.5A
8. Output power up to 75W, more than 50W, please strengthen the chip cooling (that is, must add a small heat sink)
9. High conversion efficiency, up to 96% (efficiency and input and output voltage, current, pressure difference)
10. Operating frequency: 180KHZ
11. Load adjustment rate S (I) less than 0.8 percent, voltage adjustment rate S (u) less than 0.8 percent
12. With thermal protection and short-circuit protection (but short-circuit there is an accident, try not to short-circuit)
13. Board size: about 7 x 4.7 cm
Applications:
DC/DC step-down module is used in the field of input voltage higher than the output voltage step-down, such as batteries, power transformers, DIY adjustable voltage regulator power supply, LCD monitors and LCD TVs, portable instrument power supply, telecom/network equipment, 24V car laptop power supply, industrial equipment step-down, 12V step-down to 3.3V, 12V step-down to 5V, 24V step-down to 5V, 24V step-down to 12V, 36V to 24V, etc.
